Game: R^2Studio

We have a graphics system. Why not render an R console?

This article describes the mechanics of the R2Studio ROM, which lets you run RStudio… in RStudio. See its documentation (?R2Studio) for info on how to use the ROM.

Unlike vignette("snake"), this article is not meant to be a detailed walkthrough and instead just provides an overview of how this ROM works. You can always inspect the ROM object (View(R2Studio)) to take a closer look at its code.

1. Goals

I wanted this ROM to provide the full R console experience and have some basic plotting capabilities. The goals were as follows:

accurately render an R console
provide an R environment that can save its own variables
have the ability to make a basic scatterplot
let the R environment interact with the RAM, to allow you to change ‘settings’ like font
allow for live resizing of the display

Since the console is basically a static screen, we won’t need a very high framerate. One frame per second should be plenty.

2. UI

R2Studio$draw_ui():

The UI is inspired by RStudio and features a console and plotting window. The sprites are reconstructed and drawn every frame in R2Studio$draw_ui(), allowing them to adapt to changes in the display resolution. All the function really does is make a few bordered boxes with a little text.

3. R Console

R2Studio$evaluate():

Running R code isn’t very hard, since it’s ultimately running in the main R instance. All we have to do is capture and evaluate whatever input the user gave, using base::parse() and base::eval(). We give the RAM its own little environment (stored in RAM$environment), and just tell eval() to run the captured code in that environment. This makes it so all our code only affects RAM$environment and doesn’t bleed out into the main R process (unless we tell it to).

The regular R console also prints the result of evaluations— e.g.,

> 3 + 5
[1] 8

We can get this result using utils::capture.output(). Then we just add the little ‘>’ to the expression string, and save both it and the result’s string as entries in RAM$objects$console$text.

RAM$objects$console$text
c('> 3+5', '[1] 8')

Evaluation Code [click to expand]

output = utils::capture.output(
        tryCatch(
            eval(
                parse(text = expr),
                envir = RAM$environment
            ),
            error = function(err){cat('Error in',expr,':\n',err$message)} #return error message like in regular console
            #(this error is then caught as the output of the eval, and correctly added to the R2Studio console)
    )
)

base::parse() has some quirks I haven’t ironed out yet, mainly misinterpreting expressions that use double quotes ".

3.1 Multiline Expressions

There’s also a little code to render multiline expressions properly, e.g.

> sample(
+     1:10,
+     2
+ )
[1]  1 10

Multiline inputs (made with Shift+Enter) get interpreted by rcade as multiple inputs from the same frame, so R²Studio pastes these back together before passing them as an expression string. Then newlines in the string are identified to figure out where to add that little ‘+’ on subsequent lines.

3.2 Rendering the Console

R2Studio$draw_console():

With expressions and outputs saved in order in RAM$objects$console$text, rendering the console is as easy as stacking these into one string with paste(...,sep='\n') and drawing it at the top of the console area with render.text(). Only the most recent entries are used, and only enough to fit the vertical width of the display area.

I chose not to wrap lines because of the limited space— if text wrapped, single lines would end up filling the whole console and I think it’d be harder to read overall.

4. Plotting

R2Studio$draw_plot():

Since this is more of a proof of concept, I don’t need terribly advanced plotting functionality— I just want to be able to make a nice little scatterplot.

The plot is drawn on a separate box dedicated to plotting which is drawn over the regular console. Its width can be changed with use.size(plot.width=...) (see section 5).

Drawing points on the plot is just a matter of doing a little math to scale them to the right spot based on the plot size and x/ylims, and then drawing the sprite of each point. There’s also a little handling to interpret the likes of plot(1:5) and plot(1:5,rep(1,5)) differently like R does.

The point sprites are made in R2Studio$pch(), which makes little geometric shapes at the desired cex size.

Different pch sprites at cex = c(0,0.2,0.5,1,1.5,2,2.5,...)

xlim and ylim work as plot arguments like they do in regular R, and you can use main to change the plot title.

4.1 Hooking `plot()`

In order to recognize plot() calls, and have them not be interpreted as real base::plot() calls (which would be rendered in the actual RStudio window), R2Studio$evaluate() checks if the expression starts with "plot(". If it does, it replaces the start with "R2Studio$plot(RAM,", so that gets evaluated instead; this calls R2Studio$plot(), which has all our custom plotting code.

Because I gave RAM$environment access to the RAM itself, code can edit the RAM; we can use this here to save the new plot info to RAM$objects$plotwindow, which R2Studio$draw_plot() uses to draw the plot. Access to the RAM also lets us change its ‘settings’, as shown in the next section:

5. Meta Functions

The approach to swapping out plot() for a custom function also lets us create our own new custom functions that only work in the R²Studio environment.

I use this to provide some convenience functions that interact with the game itself to change the font, resize the display area, etc. All they do is edit RAM$ROM properties, and the game is rendered in such a way that respects live changes to these— almost everything draws through obj$draw() rather than the default sprite system.

5.1 use.size()

use.size(width = NULL, height = NULL, plot.width = NULL)

Resizes the whole display or plot window; plot.width = 0 hides the plot window.

5.2 use.font()

use.font(font = NULL, kerning = NULL, linespacing = NULL, darkmode = NULL)

Alters the display’s font. darkmode=TRUE inverts the colors of the entire display.

5.3 Darkmode

The color inversion in use.font(darkmode = TRUE) is achieved by just changing the ROM’s palette— from c(' ','[]',' ') to c('[]',' ','[]'), swapping the characters for black and white. You can actually do this for any game; just run ROM$palette = c('[]',' ','[]') before quickloading.

6. R³Studio

We can also… boot up the R²Studio ROM in this environment. rcade is actually functional in this state, but you have to influence and update it manually: by using ram.input() and ram.tick(). ram.run() won’t work for several reasons, so games can only display individual frames rather than running in realtime.

Sending text is buggy, so I just had it print pi.

How cool is that! Rendering RStudio in a render of RStudio in RStudio. If you zoom in you can even see the [] pixels made up of tinier [] pixels.
